WSE251

6" Wide Wraparound with Sensor

The WSE251 is a 6” wide curved wraparound luminaire with an integrated motion sensor, expertly crafted for both style and versatility. Its robust aluminum housing with a pre-painted, baked white polyester finish ensures durability, while the frosted acrylic lens delivers even, glare-free illumination. The high-efficiency LEDs offer over 50,000 hours of service life, with 0-10V dimming and universal voltage compatibility. Perfect for commercial and institutional spaces, the WSE251 supports California Title 24 compliance, damp locations, and offers options like tunable white, emergency battery pack, and various controls. Backed by a 5-year warranty (10-year available), it exceeds modern lighting demands.
Specification Sheet
The WSE251 is a 6” wide curved wraparound luminaire with an integrated motion sensor, expertly crafted for both style and versatility. Its robust aluminum housing with a pre-painted, baked white polyester finish ensures durability, while the frosted acrylic lens delivers even, glare-free illumination. The high-efficiency LEDs offer over 50,000 hours of service life, with 0-10V dimming and universal voltage compatibility. Perfect for commercial and institutional spaces, the WSE251 supports California Title 24 compliance, damp locations, and offers options like tunable white, emergency battery pack, and various controls. Backed by a 5-year warranty (10-year available), it exceeds modern lighting demands.
Construction
  • Aluminum housing with riveted end plates
  • Side knockouts for 1/2″ conduit
  • Neoprene gasketing on end caps

Optical
  • Snap-on frosted acrylic lens
  • Two 4′ lenses per 8′ fixture

Finish
  • Pre-painted housing
  • Baked white polyester finish
  • Minimum reflectance 86%
  • High-efficiency drivers paired with long-life LEDs
  • Service life >50,000 hours (L70)
  • Universal voltage 120V ~ 277V (347V/480V available)
  • Power Factor (PF) ≥ 0.9
  • Total Harmonic Distortion (THD) ≤ 20%

Features
  • 0-10V dimming driver standard
  • Supports California Title 24 compliance

Options
  • Controls
  • Emergency battery pack
  • Tunable white (2700K – 6500K)
  • Cord & plug
  • Customization available upon request

Listing
  • UL USA and Canada Listed
  • Suitable for damp locations

Warranty
  • 5-year limited warranty
  • 10-year limited warranty available

Resources

Construction
  • Aluminum housing with riveted end plates
  • Side knockouts for 1/2″ conduit
  • Neoprene gasketing on end caps

Optical
  • Snap-on frosted acrylic lens
  • Two 4′ lenses per 8′ fixture

Finish
  • Pre-painted housing
  • Baked white polyester finish
  • Minimum reflectance 86%
  • High-efficiency drivers paired with long-life LEDs
  • Service life >50,000 hours (L70)
  • Universal voltage 120V ~ 277V (347V/480V available)
  • Power Factor (PF) ≥ 0.9
  • Total Harmonic Distortion (THD) ≤ 20%

Features
  • 0-10V dimming driver standard
  • Supports California Title 24 compliance

Options
  • Controls
  • Emergency battery pack
  • Tunable white (2700K – 6500K)
  • Cord & plug
  • Customization available upon request

Listing
  • UL USA and Canada Listed
  • Suitable for damp locations

Warranty
  • 5-year limited warranty
  • 10-year limited warranty available

Availability

  • In Stock

Lamp Source

  • Fluorescent
  • LED
  • LED Tube

Lumens

  • 1000
  • 32000

Dimming Protocol

  • 0-10 V
  • D4i
  • DALI
  • DMX
  • Forward Phase
  • Lutron
  • Step-Dimming
  • Two Wire

Ratings & Compliance

  • Build America Buy America (BABA)
  • Buy American Act (BAA)
  • Damp
  • Made in America
  • Title 24

CRI

  • 80
  • 90

Color / Finish

  • Anti-Microbial
  • Black
  • Bronze
  • Camaro Silver
  • Custom
  • Painted After Fabrication
  • Red
  • White

Controls Options

  • High Frequency Microwave
  • Passive Infrared
  • Photocell
  • Ultrasonic
  • Wireless Control

Dimensions

  • L: 48 In. W: 6 In. H: 4.6 In.
  • L: 96 In. W: 6 In. H: 4.6 In.

CCT

  • Amber
  • 2700K
  • 3000K
  • 3500K
  • 4000K
  • 5000K
  • 6500K

Dimming Range

  • 1%
  • 10%
  • 5%

Distribution

  • Direct

Dynamic LED Color

  • RGBW
  • Tunable White

Efficacy

  • 126.5
  • 128.5
  • 130.1
  • 134.9
  • 135.5
  • 136.0
  • 136.6
  • 137.9
  • 142.5
  • 142.7
  • 142.8
  • 147.4
  • 147.5
  • 147.6
  • 148.2
  • 149.4
  • 151.6

Emergency Options

  • Battery Pack
  • External Line Fuse
  • Generator Transfer Device
  • Inverter
  • Surge Protector

Lamp Base

  • FA8
  • G13
  • G5
  • R17D

Lamp Life

  • 50000

Listings

  • UL

Materials

  • Acrylic
  • Aluminum

Mounting

  • Ceiling
  • Stem
  • Suspended
  • Wall

Static LED Color

  • Blue
  • Green
  • Red

Voltage

  • 120 V
  • 120-277 V
  • 120-347 V
  • 347 V
  • 480 V
  • UNV

Warranty

  • 5 yr
  • 10 yr

Watts

  • 13.4
  • 13.5
  • 23.5
  • 26.7
  • 36.4
  • 43.7
  • 51.1
  • 74.9
  • 97.9
