INW111INW111
11″ Wide Industrial Luminaire
The INW111 is an 11” wide industrial luminaire featuring a narrow lens and housing, designed for high-performance and versatility in commercial environments. Constructed from 22-gauge cold-rolled steel with a pre-painted, baked white polyester finish, it delivers durability and a minimum 86% reflectance. The INW111 comes standard with a 0-10V dimming driver and supports California Title 24 compliance. Suitable for damp locations, it offers a range of options including sensors, tunable white (2700K-6500K), custom colors, emergency battery packs, and multiple mounting methods. With high-efficiency drivers, LEDs rated over 50,000 hours, UL listing, and up to a 10-year warranty, it ensures reliable, customizable illumination.
The INW111 is an 11” wide industrial luminaire featuring a narrow lens and housing, designed for high-performance and versatility in commercial environments. Constructed from 22-gauge cold-rolled steel with a pre-painted, baked white polyester finish, it delivers durability and a minimum 86% reflectance. The INW111 comes standard with a 0-10V dimming driver and supports California Title 24 compliance. Suitable for damp locations, it offers a range of options including sensors, tunable white (2700K-6500K), custom colors, emergency battery packs, and multiple mounting methods. With high-efficiency drivers, LEDs rated over 50,000 hours, UL listing, and up to a 10-year warranty, it ensures reliable, customizable illumination.
Construction
- 22 gauge cold-rolled steel housing
- End plates fastened to housing by screws to assure rigidity
Optical
- Frosted acrylic lens (2 per 4′ fixture)
Finish
- Pre-painted housing
- Baked white polyester finish
- Minimum reflectance 86%
High-efficiency drivers paired with long-life LEDs
- Service life >50,000 hours (L70)
- Universal voltage 120V ~ 277V (347V/480V available)
- Power Factor (PF) ≥ 0.9
- Total Harmonic Distortion (THD) ≤ 20%
Features
- 0-10V dimming driver standard
- Supports California Title 24 compliance
- Suitable for damp location
- End plates may be used as channel couplings
Options
- Sensors and controls
- Plug-in branch wiring connector
- Custom housing colors
- Tunable white available (2700K-6500K)
- Emergency battery pack
- Cable / canopy suspension systems
- Chain mount couplings
- Slotted reflector
- Customization available upon request
Listing
- UL USA and Canada Listed
- Suitable for damp locations
Warranty
- 5-year limited warranty
- 10-year limited warranty available
Resources
Construction
- 22 gauge cold-rolled steel housing
- End plates fastened to housing by screws to assure rigidity
Optical
- Frosted acrylic lens (2 per 4′ fixture)
Finish
- Pre-painted housing
- Baked white polyester finish
- Minimum reflectance 86%
High-efficiency drivers paired with long-life LEDs
- Service life >50,000 hours (L70)
- Universal voltage 120V ~ 277V (347V/480V available)
- Power Factor (PF) ≥ 0.9
- Total Harmonic Distortion (THD) ≤ 20%
Features
- 0-10V dimming driver standard
- Supports California Title 24 compliance
- Suitable for damp location
- End plates may be used as channel couplings
Options
- Sensors and controls
- Plug-in branch wiring connector
- Custom housing colors
- Tunable white available (2700K-6500K)
- Emergency battery pack
- Cable / canopy suspension systems
- Chain mount couplings
- Slotted reflector
- Customization available upon request
Listing
- UL USA and Canada Listed
- Suitable for damp locations
Warranty
- 5-year limited warranty
- 10-year limited warranty available
Availability
- Quick Ship
Lamp Source
- LED
Lumens
- 1000
- 32000
Dimming Protocol
- 0-10 V
- D4i
- DALI
- DMX
- Forward Phase
- Lutron
- Step-Dimming
- Two Wire
Ratings & Compliance
- Build America Buy America (BABA)
- Buy American Act (BAA)
- Damp
- Made in America
- Title 24
CRI
- 80
- 90
Color / Finish
- Anti-Microbial
- Black
- Bronze
- Camaro Silver
- Custom
- Painted After Fabrication
- Red
- White
Controls Options
- High Frequency Microwave
- Passive Infrared
- Photocell
- Ultrasonic
- Wireless Control
Dimensions
- L: 24 In. W: 11 In. H: 4 In.
- L: 48 In. W: 11 In. H: 4 In.
- L: 96 In. W: 11 In. H: 4 In.
CCT
- Amber
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
- 6500K
Dimming Range
- 1%
- 10%
- 5%
Dynamic LED Color
- RGBW
- Tunable White
Efficacy
- 129.1
- 133.8
- 137.2
- 137.8
- 138.7
- 141.7
- 142.0
- 142.1
- 144.7
- 145.2
- 147.4
- 148.1
- 148.8
- 153.1
- 153.4
- 153.8
- 154.5
- 157.4
- 157.8
Emergency Options
- Battery Pack
- External Line Fuse
- Generator Transfer Device
- Inverter
- Surge Protector
Lamp Life
- 50000
Listings
- UL
Materials
- Acrylic
- Steel
Mounting
- Ceiling
- Stem
- Suspended
Static LED Color
- Blue
- Green
- Red
Voltage
- 120 V
- 120-277 V
- 120-347 V
- 347 V
- 480 V
- UNV
Warranty
- 5 yr
- 10 yr
Watts
- 7.4
- 7.5
- 12.4
- 12.7
- 20.2
- 20.9
- 26.5
