WSE250
6" Wide Wraparound
The WSE250 is a 6” wide curved wraparound luminaire engineered for high efficiency and versatility. Designed with an aluminum housing, riveted end plates, and neoprene-gasketed end caps, it is built to last and suitable for damp locations. The snap-on frosted acrylic lens ensures optimal light diffusion, while the pre-painted, baked white polyester finish provides a sleek appearance with a minimum 86% reflectance. Featuring a 0-10V dimming driver, tunable white options (2700K–6500K), and emergency pack compatibility, WSE250 supports California Title 24 compliance. The luminaire is UL listed for both the USA and Canada, and comes with a 5-year (optional 10-year) limited warranty.
The WSE250 is a 6” wide curved wraparound luminaire engineered for high efficiency and versatility. Designed with an aluminum housing, riveted end plates, and neoprene-gasketed end caps, it is built to last and suitable for damp locations. The snap-on frosted acrylic lens ensures optimal light diffusion, while the pre-painted, baked white polyester finish provides a sleek appearance with a minimum 86% reflectance. Featuring a 0-10V dimming driver, tunable white options (2700K–6500K), and emergency pack compatibility, WSE250 supports California Title 24 compliance. The luminaire is UL listed for both the USA and Canada, and comes with a 5-year (optional 10-year) limited warranty.
Construction
- Aluminum housing with riveted end plates
- Side knockouts for ½” conduit
- Neoprene gasketing on end caps
Optical
- Snap-on frosted acrylic radial lens
Finish
- Pre-painted housing
- Baked white polyester finish
- Minimum reflectance 86%
- High-efficiency drivers paired with long-life LEDs
- Service life >50,000 hours (L70)
- Universal voltage 120V ~ 277V (347V/480V available)
- Power Factor (PF) ≥ 0.9
- Total Harmonic Distortion (THD) ≤ 20%
Features
- 0-10V dimming driver standard
- Supports California Title 24 compliance
- Suitable for damp locations
Options
- Controls
- Emergency battery pack
- Tunable white (2700K – 6500K)
- Cord & plug
- Customization available upon request
Listing
- UL USA and Canada Listed
- Suitable for damp locations
Warranty
- 5-year limited warranty
- 10-year limited warranty available
Resources
Construction
- Aluminum housing with riveted end plates
- Side knockouts for ½” conduit
- Neoprene gasketing on end caps
Optical
- Snap-on frosted acrylic radial lens
Finish
- Pre-painted housing
- Baked white polyester finish
- Minimum reflectance 86%
- High-efficiency drivers paired with long-life LEDs
- Service life >50,000 hours (L70)
- Universal voltage 120V ~ 277V (347V/480V available)
- Power Factor (PF) ≥ 0.9
- Total Harmonic Distortion (THD) ≤ 20%
Features
- 0-10V dimming driver standard
- Supports California Title 24 compliance
- Suitable for damp locations
Options
- Controls
- Emergency battery pack
- Tunable white (2700K – 6500K)
- Cord & plug
- Customization available upon request
Listing
- UL USA and Canada Listed
- Suitable for damp locations
Warranty
- 5-year limited warranty
- 10-year limited warranty available
Availability
- Quick Ship
Lamp Source
- Fluorescent
- LED
- LED Tube
Lumens
- 1000
- 32000
Dimming Protocol
- 0-10 V
- D4i
- DALI
- DMX
- Forward Phase
- Lutron
- Step-Dimming
- Two Wire
Ratings & Compliance
- Build America Buy America (BABA)
- Buy American Act (BAA)
- Damp
- Made in America
- Title 24
CRI
- 80
- 90
Color / Finish
- Anti-Microbial
- Black
- Bronze
- Camaro Silver
- Custom
- Painted After Fabrication
- Red
- White
Controls Options
- High Frequency Microwave
- Passive Infrared
- Photocell
- Ultrasonic
- Wireless Control
Dimensions
- L: 48 In. W: 6 In. H: 6 In.
- L: 96 In. W: 6 In. H: 6 In.
CCT
- Amber
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
- 6500K
Dimming Range
- 1%
- 10%
- 5%
Distribution
- Direct
Dynamic LED Color
- RGBW
- Tunable White
Efficacy
- 126.5
- 128.5
- 130.1
- 134.9
- 135.5
- 136.0
- 136.6
- 137.9
- 142.5
- 142.7
- 142.8
- 147.4
- 147.5
- 147.6
- 148.2
- 149.4
- 151.6
Emergency Options
- Battery Pack
- External Line Fuse
- Generator Transfer Device
- Inverter
- Surge Protector
Lamp Base
- FA8
- G13
- G5
- R17D
Lamp Life
- 50000
Listings
- UL
Materials
- Acrylic
- Aluminum
Mounting
- Ceiling
- Stem
- Suspended
- Wall
Static LED Color
- Blue
- Green
- Red
Voltage
- 120 V
- 120-277 V
- 120-347 V
- 347 V
- 480 V
- UNV
Warranty
- 5 yr
- 10 yr
Watts
- 13.4
- 13.5
- 22.7
- 23.5
- 25.8
- 26.7
- 36.4
- 43.7
- 45.3
- 51.1
- 52.7
- 71.1
- 74.9
- 81.9
- 97.9
- 99.2
- 149.2
