WSE500WSE500
10" Wide High Impact Security Wraparound
The WSE500 is a robust 10" wide high-impact security wraparound luminaire, engineered for durability and safety. Featuring a clear prismatic polycarbonate lens secured with tamper-resistant screws, its 20-gauge cold-rolled steel welded housing resists tough conditions, while a baked white powder-coated finish ensures a clean, highly reflective surface. Designed for versatile applications, it supports 0-10V dimming, California Title 24 compliance, and optional tunable white (2700K–6500K). Factory options include emergency battery backup and smart controls. Rated for damp locations and UL listed for the USA and Canada, the WSE500 is backed by a 5-year limited warranty, with a 10-year option available.
The WSE500 is a robust 10" wide high-impact security wraparound luminaire, engineered for durability and safety. Featuring a clear prismatic polycarbonate lens secured with tamper-resistant screws, its 20-gauge cold-rolled steel welded housing resists tough conditions, while a baked white powder-coated finish ensures a clean, highly reflective surface. Designed for versatile applications, it supports 0-10V dimming, California Title 24 compliance, and optional tunable white (2700K–6500K). Factory options include emergency battery backup and smart controls. Rated for damp locations and UL listed for the USA and Canada, the WSE500 is backed by a 5-year limited warranty, with a 10-year option available.
Construction
- 20 gauge cold-rolled steel welded housing
- Spot welded seams and corners
- Lens secured by four stainless steel captive tamper resistant screws
- One-way cross-linked polyethylene gasket standard
Optical
- Clear prismatic polycarbonate lens (nominal 0.187″ thick)
Finish
- Painted after fabrication
- Baked white powder-coated finish
- Minimum reflectance 90%
- High-efficiency drivers paired with long-life LEDs
- Service life >50,000 hours (L70)
- Universal voltage 120V ~ 277V (347V/480V available)
- Power Factor (PF) ≥ 0.9
- Total Harmonic Distortion (THD) ≤ 20%
Features
- Made in America, BABA & BAA Compliant
- 0-10V dimming driver standard
- Supports California Title 24 compliance
Options
- Controls
- Emergency battery pack
- Tunable white (2700K – 6500K)
- Customization available upon request
Listing
- UL USA and Canada Listed
- Suitable for damp locations
Warranty
- 5-year limited warranty
- 10-year limited warranty available
Resources
Construction
- 20 gauge cold-rolled steel welded housing
- Spot welded seams and corners
- Lens secured by four stainless steel captive tamper resistant screws
- One-way cross-linked polyethylene gasket standard
Optical
- Clear prismatic polycarbonate lens (nominal 0.187″ thick)
Finish
- Painted after fabrication
- Baked white powder-coated finish
- Minimum reflectance 90%
- High-efficiency drivers paired with long-life LEDs
- Service life >50,000 hours (L70)
- Universal voltage 120V ~ 277V (347V/480V available)
- Power Factor (PF) ≥ 0.9
- Total Harmonic Distortion (THD) ≤ 20%
Features
- Made in America, BABA & BAA Compliant
- 0-10V dimming driver standard
- Supports California Title 24 compliance
Options
- Controls
- Emergency battery pack
- Tunable white (2700K – 6500K)
- Customization available upon request
Listing
- UL USA and Canada Listed
- Suitable for damp locations
Warranty
- 5-year limited warranty
- 10-year limited warranty available
Availability
- Quick Ship
Lamp Source
- Fluorescent
- LED
- LED Tube
Lumens
- 1000
- 16000
Dimming Protocol
- 0-10 V
- D4i
- DALI
- DMX
- Forward Phase
- Lutron
- Step-Dimming
- Two Wire
Ratings & Compliance
- Build America Buy America (BABA)
- Buy American Act (BAA)
- Damp
- Made in America
- Title 24
CRI
- 80
- 90
Color / Finish
- Anti-Microbial
- Black
- Bronze
- Camaro Silver
- Custom
- Red
- White
Controls Options
- High Frequency Microwave
- Passive Infrared
- Photocell
- Ultrasonic
- Wireless Control
Dimensions
- L: 48 In. W: 10 In. H: 4.6 In.
CCT
- Amber
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
- 6500K
Dimming Range
- 1%
- 10%
- 5%
Efficacy
- 120.3
- 146.1
Emergency Options
- Battery Pack
- External Line Fuse
- Generator Transfer Device
- Inverter
- Surge Protector
Lamp Life
- 50000
Listings
- UL
Materials
- Polycarbonate
- Steel
Mounting
- Ceiling
- Stem
- Suspended
- Wall
Static LED Color
- Blue
- Green
- Red
Voltage
- 120 V
- 120-277 V
- 120-347 V
- 347 V
- 480 V
- UNV
Warranty
- 5 yr
- 10 yr
Watts
- 12.7
