GWW206GWW206
6" Wide Grid Mount Wall Wash Luminaire
The GWW206 is a versatile 6” wide wall wash recessed grid-mounted luminaire, designed for both performance and flexibility. Crafted from durable 20 gauge cold-rolled steel, it features a frameless lift-and-shift lens and a pristine baked white powder-coated finish for high reflectance. Its high-efficiency LED drivers ensure over 50,000 hours of life, with universal voltage support (120V~277V) and 0-10V dimming as standard. The GWW206 is Title 24 compliant, UL Listed for damp locations, and offers tunable white (2700K–6500K), emergency battery, and custom options. Backed by a 5-year warranty (10-year optional), it’s ideal for commercial lighting needs.
The GWW206 is a versatile 6” wide wall wash recessed grid-mounted luminaire, designed for both performance and flexibility. Crafted from durable 20 gauge cold-rolled steel, it features a frameless lift-and-shift lens and a pristine baked white powder-coated finish for high reflectance. Its high-efficiency LED drivers ensure over 50,000 hours of life, with universal voltage support (120V~277V) and 0-10V dimming as standard. The GWW206 is Title 24 compliant, UL Listed for damp locations, and offers tunable white (2700K–6500K), emergency battery, and custom options. Backed by a 5-year warranty (10-year optional), it’s ideal for commercial lighting needs.
Construction
- 20 gauge cold-rolled steel welded housing
- Frameless lift-and-shift lens
Finish
- Painted after fabrication
- Baked white powder-coated finish
- Minimum reflectance 90%
High-efficiency drivers paired with long-life LEDs
- Service life >50,000 hours (L70)
- Universal voltage 120V ~ 277V (347V/480V available)
- Power Factor (PF) ≥ 0.9
- Total Harmonic Distortion (THD) ≤ 20%
Features
- 0-10V dimming driver standard
- Supports California Title 24 compliance
Options
- Controls
- Flexible conduit
- 20 gauge cold-rolled steel housing
- Tunable white (2700K – 6500K)
- Emergency battery pack
- Customization available upon request
Listing
- UL USA and Canada Listed
- Suitable for damp locations
Warranty
- 5-year limited warranty
- 10-year limited warranty available
Resources
Construction
- 20 gauge cold-rolled steel welded housing
- Frameless lift-and-shift lens
Finish
- Painted after fabrication
- Baked white powder-coated finish
- Minimum reflectance 90%
High-efficiency drivers paired with long-life LEDs
- Service life >50,000 hours (L70)
- Universal voltage 120V ~ 277V (347V/480V available)
- Power Factor (PF) ≥ 0.9
- Total Harmonic Distortion (THD) ≤ 20%
Features
- 0-10V dimming driver standard
- Supports California Title 24 compliance
Options
- Controls
- Flexible conduit
- 20 gauge cold-rolled steel housing
- Tunable white (2700K – 6500K)
- Emergency battery pack
- Customization available upon request
Listing
- UL USA and Canada Listed
- Suitable for damp locations
Warranty
- 5-year limited warranty
- 10-year limited warranty available
Availability
- Quick Ship
Lamp Source
- Fluorescent
- LED
- LED Tube
Lumens
- 1000
- 16000
Dimming Protocol
- 0-10 V
- D4i
- DALI
- DMX
- Forward Phase
- Lutron
- Step-Dimming
- Two Wire
Ratings & Compliance
- Build America Buy America (BABA)
- Buy American Act (BAA)
- Damp
- Made in America
- Title 24
CRI
- 80
- 90
Color / Finish
- Anti-Microbial
- Black
- Bronze
- Camaro Silver
- Custom
- Painted After Fabrication
- Red
- White
Controls Options
- High Frequency Microwave
- Passive Infrared
- Photocell
- Ultrasonic
- Wireless Control
Dimensions
- L: 24 In. W: 6 In. H: 4.25 In.
- L: 48 In. W: 6 In. H: 4.25 In.
CCT
- Amber
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
- 6500K
Dimming Range
- 1%
- 10%
- 5%
Distribution
- Wall Wash
Dynamic LED Color
- RGBW
- Tunable White
Efficacy
- 74.9
Emergency Options
- Battery Pack
- External Line Fuse
- Generator Transfer Device
- Inverter
- Surge Protector
Lamp Base
- FA8
- G13
- G5
- R17D
Lamp Life
- 50000
Listings
- UL
Materials
- Steel
Mounting
- Lay-In Ceiling
- Recessed
- T-Grid
Static LED Color
- Blue
- Green
- Red
Voltage
- 120 V
- 120-277 V
- 120-347 V
- 347 V
- 480 V
- UNV
Warranty
- 5 yr
- 10 yr
