HBI609HBI609
Industrial High Impact High Bay Luminaire
The HBI609 is a rugged, high-impact gymnasium and industrial high bay luminaire, featuring a 16 ½” wide design constructed from durable cold-rolled steel with a tamper-resistant door frame and safety cables. Equipped with a high-efficiency, 0-10V dimming driver, it supports California Title 24 compliance and offers reliable performance with over 50,000 hours of LED service life. Its acrylic lens delivers excellent illumination, while a white baked powder-coated finish ensures a sleek look and 90% reflectance. The HBI609 is UL listed for damp locations, customizable with numerous options, and comes with a 5-year warranty, upgradeable to 10 years.
The HBI609 is a rugged, high-impact gymnasium and industrial high bay luminaire, featuring a 16 ½” wide design constructed from durable cold-rolled steel with a tamper-resistant door frame and safety cables. Equipped with a high-efficiency, 0-10V dimming driver, it supports California Title 24 compliance and offers reliable performance with over 50,000 hours of LED service life. Its acrylic lens delivers excellent illumination, while a white baked powder-coated finish ensures a sleek look and 90% reflectance. The HBI609 is UL listed for damp locations, customizable with numerous options, and comes with a 5-year warranty, upgradeable to 10 years.
Photometry
View All
(4)
Construction
- 22 Gauge cold-rolled steel welded housing
- 20 Gauge cold-rolled steel door frame secured by full length stainless steel piano hinge and 2 captive screws
Optical
- High impact clear prismatic acrylic lens (nominal 0.125)
Finish
- Painted after fabrication
- Baked white powder-coated finish
- Minimum reflectance 90%
High-efficiency drivers paired with long-life LEDs
- Service life >50,000 hours (L70)
- Universal voltage 120V ~ 277V (347V/480V available)
- Power Factor (PF) ≥ 0.9
- Total Harmonic Distortion (THD) ≤ 20%
Features
- 0-10V dimming driver standard
- Supports California Title 24 compliance
- Safety cables attached to door frame and LED gear tray
Options
- High (HT) ambient temperature
- Lens
- Controls
- Custom housing colors
- 11 Gauge wire guard
- Tamper proof screws
- Hub, fixture stabilizer, and pendant mount
- Emergency battery pack
- Customization available upon request
Listing
- UL USA and Canada Listed
- Suitable for damp locations
Warranty
- 5-year limited warranty
- 10-year limited warranty available
Resources
Photometry
View All
(4)
Construction
- 22 Gauge cold-rolled steel welded housing
- 20 Gauge cold-rolled steel door frame secured by full length stainless steel piano hinge and 2 captive screws
Optical
- High impact clear prismatic acrylic lens (nominal 0.125)
Finish
- Painted after fabrication
- Baked white powder-coated finish
- Minimum reflectance 90%
High-efficiency drivers paired with long-life LEDs
- Service life >50,000 hours (L70)
- Universal voltage 120V ~ 277V (347V/480V available)
- Power Factor (PF) ≥ 0.9
- Total Harmonic Distortion (THD) ≤ 20%
Features
- 0-10V dimming driver standard
- Supports California Title 24 compliance
- Safety cables attached to door frame and LED gear tray
Options
- High (HT) ambient temperature
- Lens
- Controls
- Custom housing colors
- 11 Gauge wire guard
- Tamper proof screws
- Hub, fixture stabilizer, and pendant mount
- Emergency battery pack
- Customization available upon request
Listing
- UL USA and Canada Listed
- Suitable for damp locations
Warranty
- 5-year limited warranty
- 10-year limited warranty available
Availability
- Quick Ship
Lamp Source
- Fluorescent
- LED
- LED Tube
Lumens
- 1000
- 64000
Dimming Protocol
- 0-10 V
- D4i
- DALI
- DMX
- Forward Phase
- Lutron
- Step-Dimming
- Two Wire
Ratings & Compliance
- Build America Buy America (BABA)
- Buy American Act (BAA)
- Damp
- Made in America
- Title 24
CRI
- 80
- 90
Color / Finish
- Anti-Microbial
- Black
- Bronze
- Camaro Silver
- Custom
- Red
- White
Controls Options
- High Frequency Microwave
- Passive Infrared
- Photocell
- Ultrasonic
- Wireless Control
Dimensions
- L: 48 In. W: 16.5 In. H: 5.75 In.
CCT
- Amber
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
- 6500K
Efficacy
- 125.0
- 128.6
- 129.2
- 132.4
- 133.3
- 134.5
- 134.9
- 136.6
- 136.9
- 138.0
- 138.6
- 140.8
- 142.3
- 144.1
- 146.4
- 147.4
- 153.8
Emergency Options
- Battery Pack
- External Line Fuse
- Generator Transfer Device
- Inverter
- Surge Protector
Lamp Life
- 50000
Listings
- UL
Materials
- Acrylic
- Polycarbonate
- Steel
Mounting
- Ceiling
- Stem
- Suspended
Static LED Color
- Blue
- Green
- Red
Voltage
- 120 V
- 120-277 V
- 120-347 V
- 347 V
- 480 V
- UNV
Warranty
- 5 yr
- 10 yr
Watts
- 44.1
- 68.8
- 95.1
- 123.0
- 149.6
- 170.1
- 197.3
