GCR610GCR610
1' Wide Recessed Cleanroom Luminaire for 2" Wide T-Bar Grids
The GCR610 is a premium 12” wide recessed cleanroom luminaire designed for 2” wide T-bar grids, compliant with Class 1000/10,000 and ISO Class 6/7 standards. It features a robust cold-rolled steel construction, a sealed door frame, and a durable, high-reflectance white powder-coated finish. The fixture includes high-efficiency LED drivers, 0-10V dimming, and supports California Title 24. Choose from a variety of lumen packages, color temperatures—including tunable white and colored LEDs—plus options like sensors, antimicrobial finishes, and emergency battery packs. UL listed for damp locations, the GCR610 is backed by a 5-year (optionally 10-year) warranty and offers extensive customization.
The GCR610 is a premium 12” wide recessed cleanroom luminaire designed for 2” wide T-bar grids, compliant with Class 1000/10,000 and ISO Class 6/7 standards. It features a robust cold-rolled steel construction, a sealed door frame, and a durable, high-reflectance white powder-coated finish. The fixture includes high-efficiency LED drivers, 0-10V dimming, and supports California Title 24. Choose from a variety of lumen packages, color temperatures—including tunable white and colored LEDs—plus options like sensors, antimicrobial finishes, and emergency battery packs. UL listed for damp locations, the GCR610 is backed by a 5-year (optionally 10-year) warranty and offers extensive customization.
Construction
- 22 gauge cold-rolled steel welded housing
- 20 gauge cold-rolled steel door frame secured by full length piano hinge and two captive screws
- Door frame sealed with closed cell neoprene gasket
- All parts fitted and sealed
- No unused holes or knockouts
Optical
- Inverted clear prismatic acrylic lens
- Nominal 0.125″ thickness
Finish
- Painted after fabrication
- Baked white powder-coated finish
- Minimum reflectance 90%
- High-efficiency drivers paired with long-life LEDs
- Service life >50,000 hours (L70)
- Universal voltage 120V ~ 277V (347V/480V available)
- Power Factor (PF) ≥ 0.9
- Total Harmonic Distortion (THD) ≤ 20%
Features
- Class 1000/10000
- ISO Class 6 / ISO Class 7 Equivalent
- 0-10V dimming driver standard
- Supports California Title 24 compliance
Options
- Range of lumen packages and color temperatures
- Tunable white (2700K – 6500K)
- Colored LEDs, including True/Native Amber
- Sensors and controls
- Lens options
- Antimicrobial finish
- Emergency battery pack
- Customization available upon request
Listing
- UL USA and Canada Listed
- Suitable for damp locations
Warranty
- 5-year limited warranty
- 10-year limited warranty available
Resources
Construction
- 22 gauge cold-rolled steel welded housing
- 20 gauge cold-rolled steel door frame secured by full length piano hinge and two captive screws
- Door frame sealed with closed cell neoprene gasket
- All parts fitted and sealed
- No unused holes or knockouts
Optical
- Inverted clear prismatic acrylic lens
- Nominal 0.125″ thickness
Finish
- Painted after fabrication
- Baked white powder-coated finish
- Minimum reflectance 90%
- High-efficiency drivers paired with long-life LEDs
- Service life >50,000 hours (L70)
- Universal voltage 120V ~ 277V (347V/480V available)
- Power Factor (PF) ≥ 0.9
- Total Harmonic Distortion (THD) ≤ 20%
Features
- Class 1000/10000
- ISO Class 6 / ISO Class 7 Equivalent
- 0-10V dimming driver standard
- Supports California Title 24 compliance
Options
- Range of lumen packages and color temperatures
- Tunable white (2700K – 6500K)
- Colored LEDs, including True/Native Amber
- Sensors and controls
- Lens options
- Antimicrobial finish
- Emergency battery pack
- Customization available upon request
Listing
- UL USA and Canada Listed
- Suitable for damp locations
Warranty
- 5-year limited warranty
- 10-year limited warranty available
Availability
- Quick Ship
Lamp Source
- Fluorescent
- LED
- LED Tube
Lumens
- 1000
- 16000
Dimming Protocol
- 0-10 V
- D4i
- DALI
- DMX
- Forward Phase
- Lutron
- Step-Dimming
- Two Wire
Ratings & Compliance
- Build America Buy America (BABA)
- Buy American Act (BAA)
- Damp
- Made in America
- Title 24
CRI
- 80
- 90
Color / Finish
- Anti-Microbial
- Black
- Bronze
- Camaro Silver
- Custom
- Red
- White
Controls Options
- High Frequency Microwave
- Passive Infrared
- Photocell
- Ultrasonic
- Wireless Control
Dimensions
- L: 48 In. W: 12 In. H: 6 In.
CCT
- Amber
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
- 6500K
Dimming Range
- 1%
- 10%
- 5%
Distribution
- Direct
Dynamic LED Color
- RGBW
- Tunable White
Efficacy
- 97.8
- 101.1
- 101.3
- 104.8
- 107.2
- 109.3
- 112.2
Emergency Options
- Battery Pack
- External Line Fuse
- Generator Transfer Device
- Inverter
- Surge Protector
Lamp Base
- FA8
- G13
- G5
- R17D
Lamp Life
- 50000
Listings
- UL
Materials
- Acrylic
- Steel
Mounting
- Lay-In Ceiling
- Recessed
- T-Grid
Size
- 1x4
Static LED Color
- Blue
- Green
- Red
Voltage
- 120 V
- 120-277 V
- 120-347 V
- 347 V
- 480 V
- UNV
Warranty
- 5 yr
- 10 yr
Watts
- 12.1
- 12.2
- 24.4
- 24.9
- 36.9
- 38.2
- 51.8
- 76.2
