BSW100BSW100
Ultrasonic Stairwell Luminaire
The BSW100 Ultrasonic Stairwell Wall Bracket Luminaire delivers advanced lighting performance with American-made quality. Featuring an integrated ultrasonic occupancy sensor and 0-10V dimming driver as standard, the BSW100 supports California Title 24 compliance and meets ADA low-profile requirements. Its durable 22-gauge cold-rolled steel housing, frosted acrylic lens, and baked white powder-coated finish ensure longevity and a sleek appearance. With optional wireless or wired controls, tunable white (2700K-6500K), and emergency battery backup, it offers flexible solutions for any project. Rated for damp locations, UL listed, and supported by a 5-year warranty (10-year available), it’s ideal for reliable, code-compliant stairwell lighting.
The BSW100 Ultrasonic Stairwell Wall Bracket Luminaire delivers advanced lighting performance with American-made quality. Featuring an integrated ultrasonic occupancy sensor and 0-10V dimming driver as standard, the BSW100 supports California Title 24 compliance and meets ADA low-profile requirements. Its durable 22-gauge cold-rolled steel housing, frosted acrylic lens, and baked white powder-coated finish ensure longevity and a sleek appearance. With optional wireless or wired controls, tunable white (2700K-6500K), and emergency battery backup, it offers flexible solutions for any project. Rated for damp locations, UL listed, and supported by a 5-year warranty (10-year available), it’s ideal for reliable, code-compliant stairwell lighting.
Construction
- 22 gauge cold-rolled steel welded housing
- Neoprene gasketing
Optical
- Frosted smooth acrylic snap-in lens
Finish
- Painted after fabrication
- Baked white powder-coated finish
- Minimum reflectance 90%
- High-efficiency drivers paired with long-life LEDs
- Service life >50,000 hours (L70)
- Universal voltage 120V ~ 277V (347V/480V available)
- Power Factor (PF) ≥ 0.9
- Total Harmonic Distortion (THD) ≤ 20%
Features
- Made in America, BABA & BAA Compliant
- Integrated ultrasonic occupancy sensor
- 0-10V Dimming driver standard
- ADA Compliant (low profile)
- Supports California Title 24 compliance
Options
- Wireless or wired controls
- Lens retainer and sensor cover with tamper proof screws
- Tunable white (2700K – 6500K)
- Emergency battery pack
- Customization available upon request
Listing
- UL USA and Canada Listed
- Suitable for damp locations
Warranty
- 5-year limited warranty
- 10-year limited warranty available
Resources
Construction
- 22 gauge cold-rolled steel welded housing
- Neoprene gasketing
Optical
- Frosted smooth acrylic snap-in lens
Finish
- Painted after fabrication
- Baked white powder-coated finish
- Minimum reflectance 90%
- High-efficiency drivers paired with long-life LEDs
- Service life >50,000 hours (L70)
- Universal voltage 120V ~ 277V (347V/480V available)
- Power Factor (PF) ≥ 0.9
- Total Harmonic Distortion (THD) ≤ 20%
Features
- Made in America, BABA & BAA Compliant
- Integrated ultrasonic occupancy sensor
- 0-10V Dimming driver standard
- ADA Compliant (low profile)
- Supports California Title 24 compliance
Options
- Wireless or wired controls
- Lens retainer and sensor cover with tamper proof screws
- Tunable white (2700K – 6500K)
- Emergency battery pack
- Customization available upon request
Listing
- UL USA and Canada Listed
- Suitable for damp locations
Warranty
- 5-year limited warranty
- 10-year limited warranty available
